RX6c componenten set

Productomschrijving

EXCURSION REFERENCE SERIE

• 2Ohm 16,5cm DIN,
• 120 RMS / 300 Watt
• @ 92dB 1W/m
• 63mm ET (OEM Upgradespeaker)
• 50 Hz - 21 KHz Frequency Response -

SET
PX 1S - 26mm Silk Dome Competition Tweeter * finest selected japanese Silk Dome Tweeter with ADC (Activ Damping Coating). * Air Chamber design for low FS and efficient cooling of the Neodym Motor system. * 50cm presoldered high grade tinned OFC (Oxygen Free Copper) Speakercable. Plug&Play * high grade Dual parallel switched MKP Audio Capicator for flexible modification on demands. * optional 2/4/6/8/10dB per Oct. Resistor Module, XLR2 / XLR4 / XLR6 / XLR8 / XLR10. * optional available aluminium Globe Set for the demanding Car Audio Competition.
RX 6M - High End Midbass Loudspeaker * 1`` / 25.9 mm Copper VC @ top vented Kapton Former * 30 Oz Motor Structure w. high grade Y35 Ferrite Magnet * Dual Layer natural vital Wool Cone with Glasfibre stripe reinforcments and ADC Coating * HDR (High Density & High Roll ) Rubytec Surrounds * Phase Plugged Excursion Dustcap Design * Pole Piece and bottom vented Excursion Steel Basket * Selective high extension handcrafted NOMEX Spider * PX-LPF Plug Crossover w. 14GA tinned OFC speaker cable.

• Fs:        58Hz
• SD:       132.7 sqCM
• Vas:      10.57 Ltr
• Cms:     380 µM/N
• Mms:    16,3 g
• Bl™:     4.53
• Qms:    3.25
• Qes:     0.63
• Qts:      0.52
